章节导语

当你需要构建一个复杂的AI系统时，单一的任务流程远远不够。

想象一个AI数据分析平台：它需要先收集数据、清洗数据、分析数据、生成报告、发送邮件……这些任务之间有复杂的依赖关系——有些可以并行，有些必须等待前面的任务完成。而且，某个环节失败了怎么办？重试？跳过？还是回滚？

这就是DAG工作流的价值所在。本文系统讲解复杂任务编排与执行，从DAG设计原理到工作流引擎开发，从代码实现到最佳实践，帮助你掌握构建复杂AI系统的核心能力。

一、为什么需要工作流编排

1.1 简单流程的局限

简单的线性流程（依次执行A→B→C→D）无法应对复杂场景：

任务间依赖复杂：D必须等A和B完成，E必须等C完成……手写代码管理这些依赖会变成灾难。

错误处理困难：某个任务失败了，如何重试？如何回滚？

状态管理混乱：运行到一半被中断，如何恢复？哪些任务已经完成？

监控告警缺失：只知道最终成功或失败，不知道具体卡在哪里。

1.2 DAG的优势

DAG（Directed Acyclic Graph，有向无环图）完美解决这些问题：

清晰的依赖表达：每个任务声明自己的前置依赖，系统自动计算执行顺序。

状态持久化：每个任务完成后状态持久化，重启后可恢复。

自动重试：任务失败可以配置重试策略。

并行优化：没有依赖的任务自动并行执行，最大化效率。

1.3 DAG的数学基础

DAG是一个有向图，满足：

有向：边有方向，表示任务间的依赖关系。

无环：不存在环，避免死循环。

可拓扑排序：可以线性排列，满足所有依赖约束。

import numpy as np
from typing import List, Dict, Set, Optional
from dataclasses import dataclass, field
from collections import deque
import json

@dataclass
class DAGNode:
    """DAG节点"""
    id: str
    name: str
    dependencies: List[str] = field(default_factory=list)  # 前置依赖
    status: str = "pending"  # pending/running/success/failed/skipped
    result: any = None
    error: Optional[str] = None
    retry_count: int = 0
    max_retries: int = 3

class DAG:
    """DAG有向无环图"""

    def __init__(self):
        self.nodes: Dict[str, DAGNode] = {}

    def add_node(self, node: DAGNode):
        """添加节点"""
        self.nodes[node.id] = node

    def validate(self) -> bool:
        """验证DAG是否有效"""
        # 检查循环依赖
        for node_id in self.nodes:
            if self._has_cycle_from(node_id):
                return False
        return True

    def _has_cycle_from(self, start_id: str) -> bool:
        """检查从start_id开始是否存在循环"""
        visited = set()
        rec_stack = set()

        def dfs(node_id):
            visited.add(node_id)
            rec_stack.add(node_id)

            node = self.nodes.get(node_id)
            if not node:
                return False

            for dep_id in node.dependencies:
                if dep_id not in self.nodes:
                    continue
                if dep_id in rec_stack:
                    return True
                if dep_id not in visited and dfs(dep_id):
                    return True

            rec_stack.remove(node_id)
            return False

        return dfs(start_id)

    def topological_sort(self) -> List[str]:
        """拓扑排序 - 返回任务的执行顺序"""
        in_degree = {node_id: 0 for node_id in self.nodes}

        # 计算入度
        for node in self.nodes.values():
            for dep_id in node.dependencies:
                if dep_id in in_degree:
                    in_degree[dep_id] += 1

        # 入度为0的节点先执行
        queue = deque([node_id for node_id, degree in in_degree.items() if degree == 0])
        result = []

        while queue:
            node_id = queue.popleft()
            result.append(node_id)

            # 更新相关节点的入度
            for other_id, node in self.nodes.items():
                if node_id in node.dependencies:
                    in_degree[other_id] -= 1
                    if in_degree[other_id] == 0:
                        queue.append(other_id)

        if len(result) != len(self.nodes):
            raise ValueError("存在循环依赖，DAG无效")

        return result

    def get_ready_tasks(self, completed: Set[str]) -> List[str]:
        """获取当前可执行的任务"""
        ready = []

        for node_id, node in self.nodes.items():
            if node_id in completed:
                continue
            if node.status in ["running", "success", "failed"]:
                continue

            # 检查所有依赖是否都已完成
            deps_done = all(dep_id in completed for dep_id in node.dependencies)
            if deps_done:
                ready.append(node_id)

        return ready

    def to_json(self) -> str:
        """导出为JSON"""
        return json.dumps({
            node_id: {
                "id": node.id,
                "name": node.name,
                "dependencies": node.dependencies,
                "status": node.status
            }
            for node_id, node in self.nodes.items()
        }, indent=2)

# 使用示例
dag = DAG()

# 添加节点并声明依赖
dag.add_node(DAGNode(id="a", name="数据采集", dependencies=[]))
dag.add_node(DAGNode(id="b", name="数据清洗", dependencies=["a"]))
dag.add_node(DAGNode(id="c", name="数据分析", dependencies=["a"]))
dag.add_node(DAGNode(id="d", name="生成报告", dependencies=["b", "c"]))
dag.add_node(DAGNode(id="e", name="发送邮件", dependencies=["d"]))

# 验证
print(f"DAG有效: {dag.validate()}")

# 拓扑排序
execution_order = dag.topological_sort()
print(f"执行顺序: {' -> '.join(execution_order)}")

# 获取可执行任务
print(f"初始可执行: {dag.get_ready_tasks(set())}")
print(f"a完成后可执行: {dag.get_ready_tasks({'a'})}")
print(f"b,c完成后可执行: {dag.get_ready_tasks({'a', 'b', 'c'})}")

二、工作流引擎核心实现

2.1 整体架构

工作流引擎的四大组件：

调度器（Scheduler）：负责任务的调度和分发。

执行器（Executor）：负责实际执行任务。

状态存储（State Store）：存储任务和流程的状态。

事件总线（Event Bus）：任务状态变化的发布订阅。

2.2 核心引擎实现

import time
import threading
from typing import Dict, Callable, Any, Optional
from dataclasses import dataclass, field
from enum import Enum
from collections import defaultdict
import logging

logger = logging.getLogger(__name__)

class TaskStatus(Enum):
    PENDING = "pending"
    QUEUED = "queued"
    RUNNING = "running"
    SUCCESS = "success"
    FAILED = "failed"
    RETRY = "retry"
    SKIPPED = "skipped"

@dataclass
class TaskResult:
    task_id: str
    status: TaskStatus
    output: Any = None
    error: Optional[str] = None
    duration: float = 0

class WorkflowEventBus:
    """事件总线"""

    def __init__(self):
        self.listeners: Dict[str, list] = defaultdict(list)

    def subscribe(self, event_type: str, callback: Callable):
        """订阅事件"""
        self.listeners[event_type].append(callback)

    def publish(self, event_type: str, data: Any):
        """发布事件"""
        for callback in self.listeners.get(event_type, []):
            try:
                callback(data)
            except Exception as e:
                logger.error(f"事件处理错误: {e}")

class WorkflowEngine:
    """工作流引擎"""

    def __init__(self, max_workers: int = 4):
        self.dag: Optional[DAG] = None
        self.executor_map: Dict[str, Callable] = {}
        self.state_store: Dict[str, TaskStatus] = {}
        self.max_workers = max_workers
        self.event_bus = WorkflowEventBus()
        self.lock = threading.Lock()
        self.running_tasks: Dict[str, threading.Thread] = {}

    def register_task(self, task_id: str, executor: Callable):
        """注册任务执行器"""
        self.executor_map[task_id] = executor

    def load_dag(self, dag: DAG):
        """加载DAG"""
        self.dag = dag
        self.state_store.clear()

        for node_id in dag.nodes:
            self.state_store[node_id] = TaskStatus.PENDING

    def run(self, context: Dict = None) -> Dict[str, TaskResult]:
        """运行工作流"""
        if not self.dag:
            raise ValueError("DAG未加载")

        if not self.dag.validate():
            raise ValueError("DAG无效")

        context = context or {}
        results = {}

        # 订阅任务完成事件
        self.event_bus.subscribe("task_completed", self._on_task_completed)

        # 主循环
        while True:
            completed = {tid for tid, status in self.state_store.items()
                        if status in [TaskStatus.SUCCESS, TaskStatus.FAILED, TaskStatus.SKIPPED]}

            # 检查是否全部完成
            if len(completed) == len(self.dag.nodes):
                break

            # 获取可执行任务
            ready_tasks = self.dag.get_ready_tasks(completed)

            if not ready_tasks and len(completed) < len(self.dag.nodes):
                # 没有可执行任务但未全部完成，可能是死锁
                logger.error("工作流死锁")
                break

            # 启动就绪的任务
            for task_id in ready_tasks:
                if self.state_store[task_id] == TaskStatus.PENDING:
                    self._execute_task(task_id, context, results)

            time.sleep(0.1)  # 避免CPU空转

        return results

    def _execute_task(self, task_id: str, context: Dict, results: Dict):
        """执行任务"""
        with self.lock:
            if self.state_store[task_id] != TaskStatus.PENDING:
                return
            self.state_store[task_id] = TaskStatus.QUEUED

        node = self.dag.nodes[task_id]

        def run_in_thread():
            try:
                self.state_store[task_id] = TaskStatus.RUNNING
                logger.info(f"开始执行任务: {task_id}")

                start_time = time.time()

                if task_id in self.executor_map:
                    output = self.executor_map[task_id](context)
                else:
                    output = None

                duration = time.time() - start_time

                result = TaskResult(
                    task_id=task_id,
                    status=TaskStatus.SUCCESS,
                    output=output,
                    duration=duration
                )

                with self.lock:
                    self.state_store[task_id] = TaskStatus.SUCCESS

                results[task_id] = result
                self.event_bus.publish("task_completed", result)
                logger.info(f"任务完成: {task_id}, 耗时: {duration:.2f}s")

            except Exception as e:
                logger.error(f"任务失败: {task_id}, 错误: {e}")

                result = TaskResult(
                    task_id=task_id,
                    status=TaskStatus.FAILED,
                    error=str(e)
                )

                with self.lock:
                    self.state_store[task_id] = TaskStatus.FAILED

                results[task_id] = result
                self.event_bus.publish("task_completed", result)

        thread = threading.Thread(target=run_in_thread)
        thread.start()

        with self.lock:
            self.running_tasks[task_id] = thread

    def _on_task_completed(self, result: TaskResult):
        """任务完成回调"""
        logger.info(f"收到任务完成事件: {result.task_id}")

    def get_status(self) -> Dict[str, TaskStatus]:
        """获取状态"""
        return dict(self.state_store)

# 使用示例
def data_collection(context):
    """数据采集任务"""
    time.sleep(1)
    return {"data": [1, 2, 3, 4, 5]}

def data_cleaning(context):
    """数据清洗任务"""
    time.sleep(1)
    data = context.get("collection", {}).get("data", [])
    return {"cleaned": [x for x in data if x > 2]}

def data_analysis(context):
    """数据分析任务"""
    time.sleep(1)
    cleaned = context.get("cleaning", {}).get("cleaned", [])
    return {"mean": sum(cleaned) / len(cleaned), "count": len(cleaned)}

def generate_report(context):
    """生成报告"""
    time.sleep(1)
    analysis = context.get("analysis", {})
    return f"分析完成：均值={analysis.get('mean')}, 数量={analysis.get('count')}"

def send_email(context):
    """发送邮件"""
    time.sleep(0.5)
    report = context.get("report", "")
    return f"邮件已发送: {report[:50]}..."

# 创建引擎
engine = WorkflowEngine()

# 注册任务
engine.register_task("collection", data_collection)
engine.register_task("cleaning", data_cleaning)
engine.register_task("analysis", data_analysis)
engine.register_task("report", generate_report)
engine.register_task("email", send_email)

# 创建DAG
dag = DAG()
dag.add_node(DAGNode(id="collection", name="数据采集", dependencies=[]))
dag.add_node(DAGNode(id="cleaning", name="数据清洗", dependencies=["collection"]))
dag.add_node(DAGNode(id="analysis", name="数据分析", dependencies=["collection"]))
dag.add_node(DAGNode(id="report", name="生成报告", dependencies=["cleaning", "analysis"]))
dag.add_node(DAGNode(id="email", name="发送邮件", dependencies=["report"]))

# 加载并运行
engine.load_dag(dag)
results = engine.run()

# 输出结果
print("\n执行结果:")
for task_id, result in results.items():
    status = result.status.value
    duration = f"{result.duration:.2f}s" if result.duration else "-"
    print(f"  {task_id}: {status} ({duration})")

三、任务依赖与并行优化

2.1 动态任务生成

有些场景下，任务数量在运行前是未知的，需要动态生成：

from typing import List, Dict
from dataclasses import dataclass, field
import time

@dataclass
class DynamicTask:
    """动态任务定义"""
    task_id: str
    params: Dict
    dependencies: List[str] = field(default_factory=list)

class DynamicDAGBuilder:
    """动态DAG构建器"""

    def __init__(self):
        self.tasks: Dict[str, DynamicTask] = {}
        self.context: Dict = {}

    def add_task(self, task: DynamicTask):
        """添加任务"""
        self.tasks[task.task_id] = task

    def add_dynamic_tasks(self, template: str, items: List[Dict],
                         depends_on: str = None):
        """根据数据动态生成任务"""
        for i, item in enumerate(items):
            task_id = f"{template}_{i}"

            # 依赖处理
            dependencies = []
            if depends_on:
                # 依赖所有前置任务
                dependencies.append(depends_on)

            task = DynamicTask(
                task_id=task_id,
                params=item,
                dependencies=dependencies
            )

            self.add_task(task)

    def build_dag(self) -> DAG:
        """构建DAG"""
        dag = DAG()

        for task_id, task in self.tasks.items():
            node = DAGNode(
                id=task_id,
                name=task.task_id,
                dependencies=task.dependencies
            )
            dag.add_node(node)

        return dag

    def collect_results(self, task_results: Dict[str, Any],
                       template: str) -> List[Dict]:
        """收集动态任务的结果"""
        results = []

        for task_id, result in task_results.items():
            if task_id.startswith(template):
                results.append(result)

        return results

# 使用示例
builder = DynamicDAGBuilder()

# 添加静态任务
builder.add_task(DynamicTask(task_id="fetch_urls", params={}, dependencies=[]))

# 动态添加抓取任务（从URL列表）
urls = [
    {"url": "https://example.com/1", "name": "页面1"},
    {"url": "https://example.com/2", "name": "页面2"},
    {"url": "https://example.com/3", "name": "页面3"},
]
builder.add_dynamic_tasks("scrape", urls, depends_on="fetch_urls")

# 动态添加处理任务
builder.add_task(DynamicTask(
    task_id="aggregate",
    params={},
    dependencies=[f"scrape_{i}" for i in range(len(urls))]
))

# 构建DAG
dag = builder.build_dag()
print(f"DAG节点数: {len(dag.nodes)}")
print(f"执行顺序: {' -> '.join(dag.topological_sort())}")

2.2 并行度控制

任务并行执行需要控制并发度，避免资源耗尽：

import threading
from concurrent.futures import ThreadPoolExecutor, Future
from typing import Dict, Callable, Any, List
import time

class Semaphore:
    """信号量"""
    def __init__(self, value: int):
        self.value = value
        self.lock = threading.Lock()
        self.condition = threading.Condition()
        self.waiting = 0

    def acquire(self):
        with self.condition:
            while self.value <= 0:
                self.waiting += 1
                self.condition.wait()
                self.waiting -= 1
            self.value -= 1

    def release(self):
        with self.condition:
            self.value += 1

class ParallelExecutor:
    """并行执行器"""

    def __init__(self, max_parallel: int = 4):
        self.max_parallel = max_parallel
        self.semaphore = Semaphore(max_parallel)
        self.executor = ThreadPoolExecutor(max_workers=max_parallel)
        self.futures: Dict[str, Future] = {}

    def submit(self, task_id: str, fn: Callable, *args, **kwargs) -> Future:
        """提交任务"""
        def wrapped():
            self.semaphore.acquire()
            try:
                return fn(*args, **kwargs)
            finally:
                self.semaphore.release()

        future = self.executor.submit(wrapped)
        self.futures[task_id] = future
        return future

    def wait_all(self) -> Dict[str, Any]:
        """等待所有任务完成"""
        results = {}
        for task_id, future in self.futures.items():
            try:
                results[task_id] = future.result()
            except Exception as e:
                results[task_id] = {"error": str(e)}
        return results

    def shutdown(self):
        """关闭执行器"""
        self.executor.shutdown(wait=True)

# 使用示例
def process_item(item):
    """处理单个任务"""
    time.sleep(1)
    return f"processed_{item}"

executor = ParallelExecutor(max_parallel=3)

# 提交10个任务，但最多并行3个
for i in range(10):
    executor.submit(f"task_{i}", process_item, i)

print("等待任务完成...")
results = executor.wait_all()
print(f"完成 {len(results)} 个任务")

四、错误处理与重试策略

4.1 重试策略

任务失败时的重试策略：

固定间隔：每次失败后等待固定时间重试。

指数退避：每次失败后等待时间翻倍。

熔断器：失败次数过多时暂时跳过任务。

4.2 重试机制实现

import time
from typing import Callable, Any, Optional
from dataclasses import dataclass
from enum import Enum
import logging

logger = logging.getLogger(__name__)

class BackoffStrategy(Enum):
    FIXED = "fixed"
    LINEAR = "linear"
    EXPONENTIAL = "exponential"

@dataclass
class RetryConfig:
    """重试配置"""
    max_retries: int = 3
    initial_delay: float = 1.0
    max_delay: float = 60.0
    backoff: BackoffStrategy = BackoffStrategy.EXPONENTIAL
    multiplier: float = 2.0
    retriable_errors: tuple = ()  # 可重试的错误类型

class RetryableTask:
    """可重试任务包装器"""

    def __init__(self, config: RetryConfig = None):
        self.config = config or RetryConfig()

    def execute(self, fn: Callable, *args, **kwargs) -> Any:
        """执行任务，自动重试"""
        last_error = None

        for attempt in range(self.config.max_retries + 1):
            try:
                result = fn(*args, **kwargs)
                if attempt > 0:
                    logger.info(f"任务成功重试 (尝试 {attempt + 1})")
                return result

            except Exception as e:
                last_error = e

                # 检查是否是可重试的错误
                if self.config.retriable_errors:
                    if not any(isinstance(e, err_type) for err_type in self.config.retriable_errors):
                        logger.error(f"任务失败且不可重试: {e}")
                        raise

                if attempt < self.config.max_retries:
                    delay = self._calculate_delay(attempt)
                    logger.warning(f"任务失败，{delay:.1f}秒后重试 (尝试 {attempt + 1}/{self.config.max_retries}): {e}")
                    time.sleep(delay)
                else:
                    logger.error(f"任务重试次数用尽: {e}")

        raise last_error

    def _calculate_delay(self, attempt: int) -> float:
        """计算重试延迟"""
        if self.config.backoff == BackoffStrategy.FIXED:
            delay = self.config.initial_delay

        elif self.config.backoff == BackoffStrategy.LINEAR:
            delay = self.config.initial_delay * (1 + attempt)

        elif self.config.backoff == BackoffStrategy.EXPONENTIAL:
            delay = self.config.initial_delay * (self.config.multiplier ** attempt)

        else:
            delay = self.config.initial_delay

        return min(delay, self.config.max_delay)

# 使用示例
def unreliable_task():
    """模拟不可靠任务"""
    import random
    if random.random() < 0.7:
        raise ConnectionError("网络连接失败")
    return "任务成功完成"

# 配置
config = RetryConfig(
    max_retries=3,
    initial_delay=1.0,
    backoff=BackoffStrategy.EXPONENTIAL,
    multiplier=2.0,
    retriable_errors=(ConnectionError, TimeoutError)
)

retry_handler = RetryableTask(config)

# 执行
for i in range(5):
    try:
        result = retry_handler.execute(unreliable_task)
        print(f"第{i+1}次尝试: {result}")
        break
    except ConnectionError as e:
        print(f"第{i+1}次尝试失败: {e}")

五、主流工作流框架对比

5.1 框架对比

5.2 选型建议

数据管道：优先选择Airflow或Prefect，社区成熟。

ML工作流：Prefect或Dagster，对ML场景支持更好。

云原生平台：Argo Workflows，与K8s深度集成。

关键业务：Temporal，保证执行可靠性。

六、实战：构建AI数据处理流水线

"""
AI数据处理完整流水线示例
"""

class AIDataPipeline:
    """AI数据处理流水线"""

    def __init__(self, config: dict):
        self.config = config
        self.engine = WorkflowEngine()
        self._register_tasks()

    def _register_tasks(self):
        """注册所有任务"""
        self.engine.register_task("fetch_data", self.fetch_data)
        self.engine.register_task("preprocess", self.preprocess)
        self.engine.register_task("feature_engineering", self.feature_engineering)
        self.engine.register_task("train_model", self.train_model)
        self.engine.register_task("evaluate_model", self.evaluate_model)
        self.engine.register_task("deploy_model", self.deploy_model)
        self.engine.register_task("notify", self.notify)

    def build_dag(self):
        """构建DAG"""
        dag = DAG()

        dag.add_node(DAGNode(id="fetch_data", name="数据采集", dependencies=[]))
        dag.add_node(DAGNode(id="preprocess", name="数据清洗", dependencies=["fetch_data"]))
        dag.add_node(DAGNode(id="feature_engineering", name="特征工程", dependencies=["preprocess"]))
        dag.add_node(DAGNode(id="train_model", name="模型训练", dependencies=["feature_engineering"]))
        dag.add_node(DAGNode(id="evaluate_model", name="模型评估", dependencies=["train_model"]))
        dag.add_node(DAGNode(id="deploy_model", name="模型部署", dependencies=["evaluate_model"]))
        dag.add_node(DAGNode(id="notify", name="通知", dependencies=["deploy_model"]))

        self.engine.load_dag(dag)

    def fetch_data(self, context):
        """数据采集"""
        print("1. 采集数据...")
        return {"rows": 10000}

    def preprocess(self, context):
        """数据清洗"""
        rows = context.get("fetch_data", {}).get("rows", 0)
        print(f"2. 清洗数据 ({rows} 行)...")
        return {"cleaned_rows": int(rows * 0.9)}

    def feature_engineering(self, context):
        """特征工程"""
        rows = context.get("preprocess", {}).get("cleaned_rows", 0)
        print(f"3. 特征工程 ({rows} 样本)...")
        return {"features": 50}

    def train_model(self, context):
        """模型训练"""
        features = context.get("feature_engineering", {}).get("features", 0)
        print(f"4. 训练模型 ({features} 特征)...")
        return {"model_version": "v1.0"}

    def evaluate_model(self, context):
        """模型评估"""
        version = context.get("train_model", {}).get("model_version", "")
        print(f"5. 评估模型 ({version})...")
        return {"accuracy": 0.95, "passed": True}

    def deploy_model(self, context):
        """模型部署"""
        eval_result = context.get("evaluate_model", {})
        if not eval_result.get("passed"):
            raise ValueError("模型评估未通过")
        print("6. 部署模型...")
        return {"endpoint": "https://api.example.com/model"}

    def notify(self, context):
        """发送通知"""
        endpoint = context.get("deploy_model", {}).get("endpoint", "")
        print(f"7. 发送通知 (endpoint: {endpoint})...")
        return {"notified": True}

    def run(self):
        """运行流水线"""
        self.build_dag()
        print("=" * 50)
        print("开始执行AI数据处理流水线")
        print("=" * 50)

        start_time = time.time()
        results = self.engine.run()
        duration = time.time() - start_time

        print("\n" + "=" * 50)
        print(f"流水线执行完成，耗时: {duration:.2f}s")
        print("=" * 50)

        return results

# 运行
pipeline = AIDataPipeline({})
results = pipeline.run()

for task_id, result in results.items():
    status = "✅" if result.status == TaskStatus.SUCCESS else "❌"
    print(f"{status} {task_id}: {result.status.value}")

七、总结

DAG是复杂任务编排的核心。它用图的形式清晰表达任务间的依赖关系，让复杂的业务流程变得可管理。

工作流引擎让DAG活起来。调度、执行、状态管理、错误处理，工作流引擎帮你搞定一切。

并行优化提升效率。没有依赖的任务并行执行，充分利用计算资源。

错误处理是生产级的关键。重试机制、熔断策略、回滚方案，让工作流在生产环境中稳定运行。

延伸阅读

• Airflow官方文档
• Prefect文档
• Dagster文档
• Temporal文档

课后练习

基础题：使用DAG表示法描述一个数据ETL流程。

进阶题：实现一个支持动态任务生成的工作流引擎。

挑战题：为工作流引擎添加分布式执行支持。
